PEEK Capillary Tubing

Description:

PEEK tubing is widely used for in analytical instruments and semiconductor industries due to its excellent chemical stability and corrosion resistance, such as chromatography, analytical instruments, sequencer and other testing equipments.



Features:

  • Self-Lubricating
  • Impact, Wear and Corrosion Resistance
  • High Temperature Resistance
  • High Strength, purity and light weight
OD X ID(MM) OD X ID (MM)
0.5 X 0.3-0.4 2.1 X 0.3-2.0
0.6 X 0.3-0.5 2.2 X 0.3-2.1
0.7 X 0.3-0.6 2.3 X 0.3-2.2
0.8 X 0.3-0.7 2.4 X 0.3-2.3
1/32” X 0.25/0.5 2.5 X 0.3-2.4
0.9 X 0.3-0.8 2.6 X 0.3-2.5
1.0 X 0.3-0.9 2.7 X 0.3-2.6
1.0 X 0.3-0.9 2.8 X 0.3-2.7
1.1 X 0.3-1.0 2.9 X 0.3-2.8
1.2 X 0.3-1.1 3.0 X 0.3-2.9
1.3 X 0.3-1.2 1/8” X 1/16”-2.2
1.4 X 0.3-1.3 3.2 X 0.3-3.0
1.5 X 0.3-1.4 4.95 X 4.15-4.55
1/16” X 0.1-1.2 9.52 X 8.92
1.6 X 0.3-1.5 9.86 X 9.26
1.7 X 0.3-1.6 10 X 8.7
1.8 X 0.3-1.7 12 X 10-11
1.9 X 0.3-1.8 13 X 12
2.0 X 0.3-1.9 17.1 X 16.1
22.6 X 22.1
Typical Physical Properties
Apparent Density 1.3 ±0.02 g/cm3
Tensile Strength 95 MPa
Compressive Strength (23°C) 118 MPa
Service Temperature 260 °C
